ROOTS is an extended FORTRAN language which is translated into pure FORTRAN by a preprocessor. The language was designed for use in the context of a design methodology which allows a single, automated representational technique to be used throughout the design, construction and maintenance of hierarchically structured software (See R W Witty, The design and construction of hierarchically structured software, Pragmatic Programming and Sensible Software, Online 1978). Section 2 below contains an outline description of this methodology.
ROOTS can however be used outside this context as an extended FORTRAN providing enhanced control structures, but the authors suggest that the reader pays some attention to section 2 and the possible benefits of using the software tools to the full.
ROOTS also provides performance monitoring, control and data flow tracing facilities which are integrated into the representational technique described below. These facilities can be used with existing FORTRAN programs, though this does require some effort and the results are not as easy to display as are the results when used with a true ROOTS program.
One technique for the creation of hierarchically structured software is the Step-Wise Refinement method (See N. Wirth, Program Development by Step-Wise Refinement, CACM Vol 7 No 5 Sept/Oct 1977) in which a specification is broken down or refined into a sequence of instructions. Each instruction may itself be further refined. Such software has three major structural features, sequence, parallelism and refinement. Dimensional Flowcharting is an automated graphical technique to represent these three features.
Figure 1 shows how in conventional Step-Wise Refinement there is no way of showing which instructions are derived from which specifications whereas in the Dimensional Flowchart of figure 2 the relationship is obvious. Refinement is denoted by a diagonal line connecting a specification to its refinement, ie to a sequence of instructions.
A sequence of instructions is represented as a vertically ordered list, which is executed from top to bottom. If a sequence is to be executed only once then it is called a single sequence and is indicated by the earthed symbol which is usually omitted for brevity. If a sequence is to be executed one or more times then it is called a Repeated Sequence and is indicated by the * symbol which cannot be omitted.
Conditional statements are represented by the C (conditional) symbol which, unless the specified condition is met, causes execution of the sequence to be terminated and the next (higher level) sequential instruction to be executed. The next sequential instruction is the one following the specification of the terminated sequence, see figure 3. Reaching an 'earthed' symbol causes termination of the sequence.
In general, any specification may be broken down into one or more sequences of instructions, with each sequence being executed in parallel (figure 4). A specification which is refined into executed in parallel sequences terminates if and when all its constituent sequences terminate.
Figures 2-4 show that hierarchically structured software can be represented by tree diagrams in which the three major structural features of such software are represented by lines in perpendicular directions (Figure 5). Dimensional flowchart drawings are 2-D projections of these 3-D tree structures.
SOLVE QUADRATIC EQUATION level 1 - specification INPUT COEFFICIENTS level 2 - refinement of level 1 COMPUTE ROOTS BY FORMULA OUTPUT RESULTS READ (A) level 3 - refinement of 2 level 2 instructions READ (B) READ (C) COMPUTE ROOTS BY FORMULA PRINT (A,B,C) PRINT (POSROOT,NEGROOT)
Figures 6-8 show how certain ROOTS constructs are represented as flowcharts. The direction labelled parallelism in figure 5 is used also to represent the selection of alternatives (see the IF and EPILOG examples).
Suppose a new program is to be built from scratch. The initial design work is done with flowcharts hand drawn on the backs of envelopes. The step-wise refinement method of the initial design sketches causes a proliferation of small drawings which are combined into larger drawings as the work progresses and the design firms up. Refinement of the design drawing continues until a complete program is derived, ie when all the terminal nodes of the tree structure are compilable source code. At this stage the flowchart is coded up into ROOTS. This is done by tree-walking the flowchart, ie going through the flowchart in a particular order encoding each line and statement as it is visited. The technique is easily acquired by studying the example of the ROOTS source of a program and the corresponding flowchart given later in this paper.
The machine readable source code is then presented to the ROOTS preprocessor. The output from the preprocessor is an equivalent FORTRAN program and an encoded form of the program which may be fed into a second software tool (the DFC generating program) which generates a dimensional flowchart on one of a variety of output devices. Output devices currently available include Tektronix storage tubes and the Benson 1302 pen plotter.
The output from the preprocessor is thus an exact, but neater, replica of design. This is a major help in checking the coding of a design as the flowchart should be exactly the same as the hand drawn version encoded.
Flowcharts have also been found to be a major aid to program testing as they help the programmer to appreciate the overall design when looking for bugs. As mentioned above and discussed in more detail below, program execution traces can be obtained in the same representation and program performance data can be displayed on the flowchart representing the static program structure.
They are a help to the maintenance programmer as they facilitate the learning and understanding of a program's design by retaining the hierarchical design as an integral part of the program.
The remainder of this paper describes the run-time monitoring facilities provided by the ROOTS preprocessor, which gives a flavour for the control structures provided in ROOTS and the appearance of ROOTS programs. The remaining sections describe the language in detail and the mechanics of running ROOTS programs and of flowchart generation.
It is a weakness of many language implementations that they provide no facilities for debugging and performance measurement in programs. Discovering which sections of a program consume the most resources can be exceedingly laborious and hence is rarely undertaken.
The ROOTS translator aims to provide users with facilities to measure the CPU time and IO time taken by nominated statements in the program, to generate an execution trace of nominated sections of the program and to monitor control and data flow in the program. At the language level, this is achieved by inserting monitoring statements at the start of the program which define the type of monitoring required, and then tagging those statements in the program for which monitoring is desired.
It is a further weakness of most run-time monitoring systems that the results produced are in the form of a sequential line printer listing and relating the results to the program can be exceedingly tedious. The ROOTS monitoring system is closely linked to the DFC system and by feeding the output from the monitoring system along with the flowchart code generated by the ROOTS translator into the DFC program static performance data and snap-shots of data will be displayed on the flowchart, as will be seen in figure 9.
The run-time execution trace generated by the monitor is also in the form of input data for the DFC program and this also is intended to be represented as a flowchart, as will be seen in figure 10. There are several mechanisms provided to limit the volume of tracing output generated.
The facilities provided are best described by way of examples and for this the program below will be considered. The program converts binary representations of integers to character string representations of their decimal values by iterative and recursive algorithms. This is used to illustrate the point that the monitoring system is capable of handling recursion. Recursion is permitted as an option in the PRIME FORTRAN system.
.PROG
.MONITOR SNAPS,PERFORMANCE,HISTORY,CONTROL
.TRACE
.T1: DEP(20,9),DET(3) ,RF(1) .ET
.T2: DEP(0,0),DET(10) .ET
.T3: DEP(4,4),DET(3) .ET
.ENDTRACE
.SNAP-SHOT
.SS1: DET(20),FORMAT(200),SIZE(80) .ESS
.SS2: DET(25),FORMAT(210),SIZE(80) .ESS
.SS3: DET(25),FORMAT(220),SIZE(80) .ESS
.ENDSNAP
.FILTERS
.BF1: (MOD(IT(N) ,2) .EQ.0) .EBF
.ENDFILTERS
.ENDMONITOR
.MASTER
.C DECLARATIONS
INTEGER IN,EX,NUM,J,K
INTEGER BIN(100)
INTEGER PAGE(30,100)
INTEGER ISTRNG(80)
.EC
.T1: .BEGIN
.C INITIALISE
.C I/O CHANNELS
IN = 1
EX = 1
.EC
.PARSEP
.C CLEAR OUTPUT PAGE BUFFER TO SPACES
.FOR J=1,30 .DO
.FOR K=1, 100 .DO
PAGE(J,K) = ' '
.ENDFR
.ENDFR
.EC
.EC
.C READ INPUT DATA INTO ARRAY BIN
READ(IN,100)NUM,(BIN(J),J=1,NUM)
.C FORCE LAST DATUM TO BE 9999 TO ENSURE TERMINATION
BIN(NUM) = 9999
.EC
.EC
.C CONVERT INPUT SET OF BIN NUMS TO DEC IN PAGE BUFFER
J = 1
.T1: .CYCLE K=1, 100 .TILL (1) .DO
.SS2: NUM,(BIN(J1),J1=1,NUM)
210 FORMAT('MEASURE OF SET' ,I4,1X,'MEMBERS' ,100(I10,1X))
.EXITIF(BIN(J).EQ.9999).TOSITU(1)
.T1: .C CONVERT JTH BIN TO DEC 2 WAYS,ONE PER COL
.T1: .CALL (1) B2DI(BIN(J),PAGE,J,1)
.PARSEP
.T1: .CALL (1) B2DR(BIN(J),PAGE,J,30/2+1)
.EC
J = J+1
.REPEAT
.SITU (1)
.ASSUMPTION INPUT 9999 FOUND
.OK
.LIMIT
.FAIL(EX,'9999 NOT FOUND & PAGE FULL')
.ENDCY
.EC
.C OUTPUT CONTENTS OF PAGE BUFFER
WRITE(EX,110)(BIN(K),(PAGE(J,K),J=1,30),K=1,NUM)
.EC
.STOP
.C I/O FORMATS
100 FORMAT(I10)
110 FORMAT(I10,2X,30 A1)
.EC
.ENDM
.LEVEL 1
.SUBROUTINE B2DR(BINARY,PAGE,LINE,START)
.C DECLARATIONS
.C PARAMETERS
INTEGER BINARY,PAGE(30,100),LINE,START
.EC
.C LOCALS
INTEGER NCP,BIN
.EC
.C FUNCTIONS
.IG NONE
.EC
.EC
.BEGIN
.C OUTPUT SIGN & MAGNITUDE OF BINARY
.C OUTPUT SIGN OF BINARY
.IF(BINARY.LT.0).THEN
.CALL(3) PRINT('-' ,PAGE,LINE,START)
.ELSE
.CALL(3) PRINT('+' ,PAGE ,LINE ,START)
.ENDIF
.EC
.PARSEP
.C OUTPUT MAGNITUDE IN DECIMAL CHARSFROM MOST SIG DIGIT TO LEAST
BIN = IABS(BINARY)
NCP = START+1
.T1: .CALL (2) PB2DR(BIN,PAGE,LINE,NCP)
.EC
.EC
.RETURN
.END
.SETSEP
.SUBROUTINE B2DI(BINARY,PAGE,LINE,START)
.C DECLARATIONS
.C PARAMETERS
INTEGER BINARY,PAGE(30,100),LINE,START
.EC
.C LOCALS
INTEGER NCP,BIN,I,REM
.EC
.C FUNCTIONS
INTEGER DIGITS
.EC
.EC
.BEGIN
.C OUTPUT SIGN & MAGNITUDE OF BINARY
.C OUTPUT SIGN OF BINARY
.IF(BINARY.LT.0).THEN
.CALL(3) PRINT('-' ,PAGE,LINE,START)
.ELSE
.CALL(3) PRINT('+',PAGE,LINE,START)
.ENDIF
.EC
.PARSEP
.C OUTPUT MAGNITUDE IN DECIMAL CHARSFROM LEAST SIG DIGIT TO MOST
BIN = IABS(BINARY)
NCP = START+DIGITS(BIN)
.CALL(2) PB2DI(BIN,PAGE,LINE,NCP)
.EC
.EC
.RETURN
.END
.ENDLEV
.LEVEL 2
.SUBROUTINE PB2DR(BINARY,PAGE,LINE,NCP)
.C DECLARATIONS
.C PARAMETERS
INTEGER BINARY,PAGE(30,100),LINE,NCP
.EC
.C LOCALS
INTEGER LSTDIG,BIN,ISTRNG(80),CHR
.EC
.C FUNCTIONS
INTEGER CHAR
.EC
.EC
.T1: .BEGIN
.IF(BINARY.GE.10).THEN
BIN = BINARY/10
.T1: .CALL (*) PB2DR(BIN,PAGE,LINE,NCP)
.ELSE
.NULL
.ENDIF
.C DETATCH LEAST SIG DIGIT
LSTDIG = MOD(BINARY,10)
.EC
.C PRINT LEAST SIG DIGIT
CHR = CHAR(LSTDIG)
.SS1: CHR,LINE,NCP
.CALL(3) PRINT(CHR,PAGE,LINE,NCP)
NCP = NCP+1
.EC
200 FORMAT ( 'CHARACTER', 1X,A1, 1X, 'LINE' ,I4, 1X, 'COLUMN' ,I4)
.RETURN
.END
.SETSEP
.SUBROUTINE PB2DI(BINARY,PAGE,LINE,NCP)
.C DECLARATIONS
.C PARAMETERS
INTEGER BINARY,PAGE(30,100),LINE,NCP
.EC
.C LOCALS
INTEGER LSTDIG,J,BIN,ISTRNG(80),CHR
.EC
.C FUNCTIONS
INTEGER CHAR
.EC
.EC
.BEGIN
BIN = BINARY
.T2: .CYCLE J = 1 ,30 .TILL (1) .DO
.C DETATCH JTH LEAST SIG DIGIT
LSTDIG = MOD(BIN,10)
BIN = BIN/10
.EC
.T3: .C PRINT JTH LEAST SIG DIGIT
CHR = CHAR(LSTDIG)
.SS1: CHR,LINE,NCP
.T2: .CALL(3) PRINT(CHR,PAGE,LINE,NCP)
NCP = NCP-1
.EC
.EXITIF(BIN.EQ.0).TOSITU(1)
.REPEAT
.SITU (1)
.OK
.LIMIT
.FAIL(1,'PB2DI LOOP GUARD ERROR')
.ENDCY
200 FORMAT ('CHARACTER' , 1X, A1 , 1X, 'LINE' ,I4, 1X, 'COLUMN' , I4)
.RETURN
.END
.ENDLEV
.LEVEL 3
.SUBROUTINE PRINT(CHCODE,PAGE,LINE,WIDPOS)
.C DECLARATIONS
.C PARAMETERS
INTEGER CHCODE,PAGE(30,100),LINE,WIDPOS
.EC
.EC
.T2: .BEGIN
.T2: PAGE(WIDPOS,LINE) = CHCODE
.RETURN
.END
.SETSEP
.INTEGER FUNCTION CHAR(INT)
.C DECLARATIONS
.C PARAMETERS
INTEGER INT
.EC
.EC
.BEGIN
.IF(INT.EQ.O) .THEN
CHAR = '0'
.ELIF(INT.EQ.1) .THEN
CHAR = '1'
.ELIF(INT.EQ.2) .THEN
CHAR = '2'
.ELIF(INT.EQ.3).THEN
CHAR = '3'
.ELIF(INT.EQ.4) .THEN
CHAR = '4'
.ELIF(INT.EQ.5) .THEN
CHAR = '5'
.ELIF(INT.EQ.6) .THEN
CHAR = '6'
.ELIF(INT.EQ.7) .THEN
CHAR = '7'
.ELIF(INT.EQ.8) .THEN
CHAR = '8'
.ELIF(INT.EQ.9) .THEN
CHAR = '9'
.ELSE
.FAIL(1,'FUNC CHAR PARAM NOT DIGIT')
.ENDIF
.RETURN
.END
.SETSEP
.INTEGER FUNCTION DIGITS(POSINT)
.C DECLARATIONS
.C PARAMETERS
INTEGER POSINT
.EC
.C FUNCTIONS
INTEGER DIGTSR
.EC
.EC
.BEGIN
.IF(POSINT.GE.10).THEN
DIGITS = 1+DIGTSR(POSINT/10)
.ELSE
DIGITS = 1
.ENDIF
.RETURN
.END
.ENDLEV
.LEVEL 4
.INTEGER FUNCTION DIGTSR(INT)
INTEGER INT,DIGITS
.BEGIN
DIGTSR = DIGITS(INT)
.RETURN
.END
.ENDLEV
.ENDP
The type of run-time monitoring required is requested by the inclusion of a .MONITOR section at the head of the program as shown below.
.MONITOR PERFORMANCE, HISTORY, CONTROL, SNAPS
.TRACE
.T1: DEP(20, 7) ,DET(3) ,RF(1) .ET
.T2 : DEP(0 ,0) ,DET (10) ,RF (1) .ET
.ENDTRACE
.SNAP-SHOT
.SS1: DET(20) ,FORMAT(200) ,SIZE(80) .ESS
.SS2: DET(25) ,FORMAT(210),SIZE(80) .ESS
.ENDSNAP
.FILTERS
.BF1: (MOD(IT(N) ,2) .EQ.0) .EBF
.ENDFILTERS
.ENDMONITOR
The monitoring categories required are specified by the keywords following .MONITOR. The statement above represents all available monitoring categories. TRACE - ENDTRACE, SNAP-SHOT - ENDSNAP and FILTERS - ENDFILTERS are optional sections which control the details of monitoring.
The most general form of trace statement possible is indicated above. The number following .T is the tracing level being defined. When statements in the program are tagged for monitoring, the tag includes a tracing level, which indexes a set of tracing parameters defined in .TRACE.
Tracing parameters are set as follows:
The association of a level of detail with each statement tagged for tracing provides a mechanism whereby the user may select at run-time a subset of these statements to be actually traced. The user specifies at run-time a level of detail, and only those statements with
detail ≤ run-time detail
will appear in the tracing output.
The specification of a repetition filter is a method for selecting the iterations of a loop to be traced. The filter to be associated with a particular tracing level is defined by an index into the set of filters (specified in the .FILTERS section). Thus in the example above, the filter
(MOD(IT(N),2).EQ.0)
is associated with tracing level 1. Statements are only traced when the value of the associated filter is .TRUE. (and some other conditions are satisfied). Associated with each loop in the program is an iteration counter, assigned the value zero before the loop is entered and incremented by one at the start of each iteration of the loop. The function IT(N) is a function of type INTEGER*4 provided by the monitor which returns the current value of the iteration counter. Thus the repetition filter above will cause all odd numbered iterations not to be traced.
Note that any routine in which IT(N) is invoked must include a declaration:
INTEGER*4 IT
this is NOT included automatically by the translator. Failure to include such a declaration will lead to spurious results (the filter will always return the value 0).
The pruning data specified by DEP allow the user to control the depth to which the trace is allowed to grow and how much of the trace is to be retained as levels of refinement are terminated.
The motivation behind this is that if the execution of a refinement terminates unexpectedly (for example a .FAIL statement is executed or the condition specified in a .ASSERTION statement yields the value .FALSE.) one can have a very detailed execution trace to work from. If the execution is successful, one is not in general interested in the detail of the execution so this can be discarded from the trace.
Consider the section of code:
.T3: .C PRINT JTH LEAST SIG DIGIT
.T2: CALL PRINT(CHAR(LSTDIG),PAGE,LINE,NCP)
.EC
..........
.SUBROUTINE PRINT(CHCODE,PAGE,LINE,WIDPOS)
.T2: .BEGIN
.T2: PAGE(WIDPOS,LINE) = CHCODE
.RETURN
.END
Execution of this code will produce the trace
Depths of refinement are indicated at the head of each refinement in the text <number>=RD. Suppose the statement
.C PRINT JTH LEAST SIG DIGIT
is tagged with the tag .T3 where tracing level 3 is defined by:
.T3: DEP(2,1) ,DET(3) .ET
The first parameter specified in DEP (DOWN) is the number of refinements of the current refinement which are to be traced. This value is used to calculate a new value of the maximum depth of refinement to be traced (MDRT), which is given by:
MDRT = MAX (MDRT,MDRT + DOWN)
Thus in this example, since the value of DOWN associated with tracing level 2 is zero, the statements CALL PRINT and BEGIN PRINT would be traced, but the refinements of BEGIN PRINT would not.
The second parameter specified in DEP (UP) is the number of refinements of the current refinement to be saved. This value is used when a refinement terminates to decide whether the refinement should be saved in the tracing buffer or discarded. The maximum depth of refinement to be saved (MDRS) is calculated as for MDRT, ie:
MDRS = MAX(MDRS,MDRS + UP)
Thus in this example, if MDRS has the value 7 when the statement PRINT JTH LEAST SIG DIGIT is obeyed, the new value calculated will be 8. Thus on termination of all refinements with depths greater than 8, any statements traced will be discarded. The above example will appear as:
The SNAP-SHOT section specifies how current data values are to be recorded in the tracing buffers and the circular snap-shot buffers. The parameter, specified by DET is the level of detail which controls whether anything will be recorded in the buffer. FORMAT specifies the label of a FORMAT statement which will be used as a template for writing the data values into the tracing buffer. SIZE specifies how many characters of the string produced by writing the values into a buffer according to FORMAT are to be saved. Snap-shots are invoked by a program statement of the form:
.SS<number>: <name list>
for example:
.SS1: I,J,K
<number> is an index into the set of snap-shot definitions in .SNAP-SHOT. Thus with the snap-shot definitions given earlier, 80 characters of the string produced by writing the values of I, J, K, into a buffer according to FORMAT statement 200 will be recorded in the tracing buffer if the detail level specified at run-time is greater than 20. Statement 200 might be:
200 FORMAT('VALUES OF I, J, K' ,2X,3(I6,2X))
Every routine producing snap-shots should include the declaration of a array:
INTEGER ISTRNG(<n>)
where the dimension <n> is large enough to hold the number of characters specified by the SIZE parameter of the .SS statement defining the snap-shot. Thus for a maximum SIZE of 80 characters, the array should be dimensioned at 40, as 2 characters are stored per word.
The run-time monitor will produce an output file containing snap-shot information in the format:
STATEMENT NUMBER 1
ENTRY ITERATION AND SNAP-SHOT
-2 ( 1) MEASURE OF SET 3 MEMBERS -123 5436 9999
-1 ( 2) MEASURE OF SET 3 MEMBERS -123 5436 9999
0 ( 3) MEASURE OF SET 3 MEMBERS -123 5436 9999
STATEMENT NUMBER 2
ENTRY ITERATION AND SNAP-SHOT
-6 ( 1) CHARACTER 1 LINE 1 COLUMN 17
-5 ( 1) CHARACTER 2 LINE 1 COLUMN 18
-4 ( 1) CHARACTER 3 LINE 1 COLUMN 19
-3 ( 2) CHARACTER 5 LINE 2 COLUMN 17
-2 ( 2) CHARACTER 4 LINE 2 COLUMN 18
-1 ( 2) CHARACTER 3 LINE 2 COLUMN 19
0 ( 2) CHARACTER 6 LINE 2 COLUMN 20
STATEMENT NUMBER 3
ENTRY ITERATION AND SNAP-SHOT
-6 ( 1) CHARACTER 3 LINE 1 COLUMN 4
-5 ( 2) CHARACTER 2 LINE 1 COLUMN 3
-4 ( 3) CHARACTER 1 LINE 1 COLUMN 2
-3 ( 1) CHARACTER 6 LINE 2 COLUMN 5
-2 ( 2) CHARACTER 3 LINE 2 COLUMN 4
-1 ( 3) CHARACTER 4 LINE 2 COLUMN 3
0 ( 4) CHARACTER 5 LINE 2 COLUMN 2
ENTRY records the position of the snap-shot in the circular snap-shot buffers (least recent first). The value of the current iteration counter is recorded with each entry which is of value in tying up snap-shots and program execution.
If HISTORY tracing is invoked, snap-shots will also appear in the history trace file and will be displayed in context if a flowchart is drawn of this data. The mechanics of this operation are discussed in section 14 on running the flowchart generation program.
The tracing mechanism operates in one of two modes, either dumping information to the tracing file as it is generated (history buffer) or by maintaining a circular buffer of information and dumping the buffer when the monitor is terminated. The latter mode is useful during later stages of debugging as it produces significantly less output than the history buffer, typically giving an execution trace of the last 100 statements executed. Tracing mode is selected at run-time.
Tracing mode can also be changed dynamically at execution time by including statements
.HISTORICAL TRACE .CIRCULAR TRACE
in the ROOTS source code. Execution of these statements switches the trace mode to history buffer or circular buffer respectively. Examples of a circular trace generated is appended (see figure 11). The statement .CIRCULAR TRACE was inserted after the statement
J = J+1
in the main loop of the example program.
If CONTROL monitoring is requested, the file produced by the monitoring package will contain information of the form
CIRCULAR CONTROL BUFFER
EXEC. ORDER STMT. NO. ITERATION
-98 3 1
-97 4 1
-96 5 1
-95 6 1
-94 24 1
-93 25 1
-92 15 1
-91 16 1
-90 17 1
-89 18 1
-88 19 1
-87 24 1
-86 25 1
-85 20 1
-84 17 2
-83 18 2
-82 19 2
-81 24 2
.......
-11 14 2
-10 13 2
-9 24 2
-8 25 2
-7 24 2
-6 25 2
-5 24 2
-4 25 2
-3 24 2
-2 25 2
-1 9 1
0 10 1
The monitoring package stores the statement numbers and associated iteration counter of the last 100 statements executed by the program. Statement numbers can be ascertained from the flowchart of the program. Numbers used to identify performance, control and snap-shot data are given in parentheses after each tagged statement, for example:
CONVERT JTH BIN TO DEC 2 WAYS, ONE PER COL (PF NO 3 CL NO 3)
The performance (PF NO) identifier of this statement is 3, the control statement number (CL NO) is also 3.
If PERFORMANCE monitoring is requested, the file produced by the monitoring package will contain information of the form:
PERFORMANCE MONITOR
STMNO CPU-TIME IO-TIME FREQUENCY MAX.REC.DEP CURR.REC.DEP
1 855 1 1 1 0
2 799 1 1 1 0
3 793 1 1 1 0
4 780 1 2 1 0
5 409 0 2 1 0
6 407 0 2 1 0
7 363 1 2 1 0
8 360 1 2 1 0
9 3 0 1 1 0
10 0 0 1 1 0
11 0 0 0 0 0
12 332 1 2 1 0
13 326 1 7 4 0
14 189 1 5 3 0
15 359 0 2 1 0
16 347 0 2 1 0
17 322 0 7 1 0
18 199 0 7 1 0
19 43 0 7 1 0
20 3 0 7 1 0
21 6 0 2 1 0
22 0 0 2 1 0
23 0 0 0 0 0
24 58 0 18 1 0
25 10 0 18 1 0
Statement numbers can be related to statements as discussed above. PRIME routines CTIM$A and DTIM$A (see PRIME Manual for descriptions of these) are used to measure the CPU times and IO times used by statements. CPU times and IO times are recorded in units of 1/100th of a second.
Consider the program fragment
The execution time for the statement PRINT JTH LEAST SIG DIGIT will be given by the difference in CPU time used at the start of the statement
.EXITIF(BIN.EQ.0).TOSITU(1)
and the CPU time used at the point before the statement
PRINT JTH LEAST SIG DIGIT
As far as possible resources used by subroutine calls to the monitor are subtracted from the CPU-TIME figures reported, but some proportion of the monitor overheads will be used, because some instructions must be executed before CPU time monitoring can be turned off. Thus the figures reported should be treated with some caution and fine grain effects should be ignored.
Monitor overhead is measured by the monitor and is printed out at the end of the program run (see attached example).
The column headed FREQUENCY records the execution frequencies of the statements monitored. MAX.REC.DEP reports the maximum depth of recursion of the statement and CURR.REC.DEP records the depth of recursion of the statement when monitoring terminated.
In general performance monitoring information will be displayed as a flowchart of the program under consideration, in preference to direct examination of the file produced by the monitor. The technique for doing this is described in the section on running the flowchart generation program. Bizarre results can be produced if statements tagged for tracing are not included on the flowchart drawn (ie are tagged to be abstracted).
All reserved words in ROOTS are preceded by the symbol '.'. ROOTS source text must start in or after column 7 and must not go beyond column 72 of the line. FORTRAN source may be intermingled with ROOTS constructs as desired, but only 'pure' FORTRAN source may be continued to a second or subsequent line.
If the FORTRAN code generated by a ROOTS statement exceeds 72 characters, it will be automatically continued to the next line. This should cause no problems.
ROOTS reserved words may not contain embedded spaces. Thus:
.I F(.TRUE.).T H E N
is illegal.
The ROOTS preprocessor generates labels in the range 20000 to 29999. Variable names KT<n> where <n> is in the range 0001 to 9999 are generated by the preprocessor in the translation of the .CYCLE statement and hence should not be used in the source fed to the preprocessor.
We introduce the notation
The syntax is:
.IF(<be>).THEN <ls> .ELIF(<be>).THEN <ls> .ELIF(<be>).THEN <ls> .ELSE <ls> .ENDIF
The .ELSE clause is mandatory. The statement may contain any number (including zero) of .ELIF clauses. The code generated is:
IF(.NOT.(<be>))GOTO 20000
<ls>
GOTO 20001
2000 IF(.NOT.(<be>))GOTO 20002
<ls>
GOTO 20001
2002 IF(.NOT.(<be>))GOTO 20003
<ls>
GOTO 20001
2003 CONTINUE
<ls>
2001 CONTINUE
Further syntatic restrictions are:
The conditionals are evaluated serially until one is TRUE, the <ls> is obeyed and control passes to the end of the statement.
In the syntax below <int> is an INTEGER variable, and <nc> is the number of cases in the statement. The syntax is:
.SWITCH(<int>,<nc>) .CASE(1) <ls> .CASE(2) <ls> .CASE(3) <ls> .OUT-OF-RANGE <ls> .ENDSW
The code generated, when number of cases is 3, is:
IF(<int>.LT.1 .OR. <int>.GT.<nc>)GOTO 20004
GOTO(20001,20002,20003),<int>
20001 CONTINUE
<ls>
GOTO 20005
20002 CONTINUE
<ls>
GOTO 20005
20003 CONTINUE
<ls>
GOTO 20005
20004 CONTINUE
<ls>
GOTO 20005
20005 CONTINUE
The .OUT-OF-RANGE statement is mandatory.
The language contains three loop statements, .FOR-.ENDFR is a simple iteration statement akin to the FORTRAN DO statement. .CYCLE is a general Zahn loop construct, .WHILE will be familiar from ALGOL.
The syntax and code generated are:
.WHILE (<be>).DO
<ls>
.ENDWH
20000 IF (.NOT.(<be>))GOTO 20001
<ls>
GOTO 20000
20001 CONTINUE
Note that .WHlLE (<be>) and .ENDWH must occupy single lines.
The syntax and code generated are:
.FOR I = N1,N2,N3 .DO
<ls>
.ENDFR
DO 20000 I = N1,N2,N3
<ls>
20000 CONTINUE
<ls>
All reserved words with the exception of .UNTIL in this statement are mandatory. In line with the syntax of .IF and .SWITCH statements, .LIMIT must be the last clause of the epilog before .ENDCY.
The .UNTIL construct has been introduced to provide a mechanism for representing the statements of which .EXITIF is a refinement. For example:
.UNTIL(End of file).IE .UNTIL(Top bit set).IE .EXITIF(REPLY.LT.O).TOSITU(2)
In the description below, <ns> is the number of distinct exits from the loop, ie. the number of .SITU clauses to follow.
The syntax is as follows followed by the code generated for <ns>=2:
.CYCLE I=N1,N2,N3 .TILL(<ns>).DO
<ls>
.UNTIL (<text>).IE
.EXITIF(<be>).TOSITU(1)
<ls>
.EXITIF(<be>).TOSITU(2)
<ls>
.REPEAT
.SITU(1)
<ls>
.SITU(2)
<ls>
.LIMIT
<ls>
.ENDCY
DO 20000 I = N1,N2,N3
<ls>
ASSIGN 20003 TO KT0001
IF(<be>) GOTO 20002
<ls>
ASSIGN 20004 TO KT0001
IF(<be>) GOTO 20002
<ls>
20000 CONTINUE
ASSIGN 20005 TO KT0001
20002 CONTINUE
GOTO KT0001
20003 CONTINUE
<ls>
GOTO 20001
20004 CONTINUE
<ls>
GOTO 20001
20005 CONTINUE
<ls>
20001 CONTINUE
A refinement is introduced by either of the statements:
.C <text>
.N
<lines of text>
.EN
and is terminated by the statement
.EC
For example:
.C ADVANCE OUTPUT BUFFER POINTER
OBUFPR = OBUFPR + 1
.EC
Parallel sequences may be represented by the syntax:
.C or .N ..... .EN
<ls>
.PARSEP
<ls>
.EC
Any number of .PARSEP ... <ls> are allowed.
These statements have been found to be extremely useful in the language DRIL. The code generated by both will be CONTINUE.
The syntax of this statement and code generated are:
.FAIL(<channel number>,'<message>')
WRITE(<channel number>,<label>)
<label> FORMAT('(<message>')
IF( .TRUE. )STOP
The last line is necessarily contorted to get round the problem of no path to statement in the PRIME FORTRAN compiler.
ROOTS recognises the statements
.BLOCK DATA
.SUBROUTINE
.FUNCTION
.INTEGER FUNCTION
.INTEGER*4 FUNCTION
.REAL FUNCTION
.DOUBLE PRECISION FUNCTION
.LOGICAL FUNCTION
.COMPLEX FUNCTION
.RETURN
.STOP
.END
Note that single spaces must appear in these statements where shown above. The code generated by .STOP is:
IF(.TRUE.)STOP
To facilitate program monitoring ROOTS recognises statements of the form:
.CALL .....
Two forms of the statement are allowed:
.CALL <name>(<argument list>)
ie the addition of a period (.) to the front of a FORTRAN CALL statement. The second form allows the insertion of the routine level after CALL:
.CALL(<level>)<name>(<argument list>)
Recursive calls are denoted by the symbol * in place of <level>.
The notion of subroutine level comes from a consideration of call graphs, a routine at level n can be called by routines at all levels m≤n and may call routines at all levels k≥n.
There is a need to delimit the MASTER segment (in 1900 terminology) of a program and hence we introduce:
.MASTER .ENDM
It is also useful to know where the code of a routine begins and hence we introduce
.BEGIN
The statements
.PROG <text string> .ENDP
delimit the entire source.
To facilitate the representation of the level concept in flowcharts, the statements:
.LEVEL <number> .SETSEP .ENDLEV
are introduced. The structure of a ROOTS program is then represented by the syntax:
.PROG .MASTER ... .ENDM .LEVEL 1 .SUBROUTINE ... .END .SETSEP .SUBROUTINE ... .END .SETSEP .SUBROUTINE ... .END .ENDLEV .LEVEL 2 .ENDLEV .ENDP
It is a frequent source of annoyance that many software tools do not have an equivalent of the $INSERT Facility of the PRIME FORTRAN compiler. ROOTS has such a facility which will increase the utility of tools such as PFORT for investigation of the intermediate FORTRAN code generated by ROOTS.
The construct is:
.ADD <filename>
adds the text in <filename> and generates a flowchart of the entire source text, unless preceded by an edit tag.
.ADD
can be nested to a finite depth.
Monitoring levels are defined by statements enclosed by the reserved words:
.MONITOR .ENDMONITOR
Trace, filter and snap-shot levels are defined within this section:
.MONITOR .TRACE .T1: DEP(20,7),DET(3),RF(1) .ET .T2: DEP(0,0),DET(10),RF(1) .ET .ENDTRACE .SNAP-SHOT .SS1: DET(20),FORMAT(200) ,SIZE(80) .ESS .SS2: DET(25),FORMAT(210) ,SIZE(80) .ESS .ENDSNAP .FILTERS .SF1: (MOD(IT(N),2).EQ.O) .EBF .ENDFILTERS .ENDMONITOR
Statements to be monitored are tagged as follows:
.T <level>: <statement>
where <level> indexes a tracing level defined in the .TRACE section of the MONITOR statement.
Snap shots are produced by the statement:
.SS<index>: <list of variables>
and <index> refers to a snap shot set up in the SNAP-SHOT section of the MONITOR statement.
To invoke monitoring, the .MONITOR statement must be followed by keywords (in any order) indicating the monitoring categories required. The most general form is:
.MONITOR PERFORMANCE,HISTORY,CONTROL,SNAPS
The syntax of this statement is:
.ASSUMPTION <number>: (<text>)
the code generated is as for a comment statement.
The syntax of this statement is:
.ASSERTION <number>: (<be>)
If the statement is not tagged by a monitoring tag (e.g. .T1:) the code generated is as for a comment statement.
If the statement is tagged, for example:
.T1: .ASSERTION 1: (N.GT.M)
then the code generated is:
IF(<be>) GOTO 20000
STOP <number>
20000 CONTINUE
It is often the case that one does not wish to produce the entire flowchart of a program, merely the sections of current interest. An editing mechanism is defined within the syntax.
ROOTS statements may be tagged to indicate that the refinement of the statement is not to be drawn by tagging them with .K <number>: for example:
.SWITCH (NUM,3) .K 1: .CASE(1) .K 2: .CASE(2)
Each tag .K <number> may take the value REF (refined) meaning draw the sequence, or ABS (abstracted) meaning omit the sequence. Values are assigned within the .EDIT statement which must appear after the .PROG statement and before the tags defined are used. The maximum number of tags that may be defined is 20. The syntax of the statement is:
.EDIT
.K <number>:(REF or ABS) .EK
.K <number>:(REF or ABS) .EK
...........
.ENDEDIT
For example, if K1 and K2 are defined as REF, the program fragment above would be drawn as:
If however K1 is defined as ABS, the fragment will be drawn as:
This section describes the operation of the ROOTS preprocessor. ROOTS is invoked by the macro command:
$ROOTS <input file>,<code file>,<flowchart file>,<options>
where:
<input file> is the name of the file containing ROOTS source
<code file> is the name of a file into which the FORTRAN code generated by the preprocessor will be written
<flowchart file> is the name of a file into which the code to drive the flowchart generation program will be written
<options> specify whether FORTRAN and/or flowchart code is to be produced
FORTRAN code is generated by specifying the boolean FORT. Flowchart code is generated by specifying the boolean FLOW.
Default names of
C-<input file> F-<input file>
are provided for <code file> and <flowchart file> respectively. Thus, for example if a ROOTS program is contained in file SOURCE, FORTRAN and flowchart code can be generated by the command:
$ROOTS SOURCE,,,FORT,FLOW
The FORTRAN code will be written in file C-SOURCE, the flowcharting code in file F-SOURCE.
See the terminal dialogue below (commands typed by user underlined, text following a '[' is an explanatory comment).
OK, $ROOTS SOURCE,, ,FORT.FLOW OK, I SOURCE OK, O C-SOURCE 3 2 OK, O F-SOURCE 4 2 OK, SEG PROGRAM>#ROOTSTRANS GO FOREST V 2.2 DO YOU WANT FLOWCHART CODE (Y/N) Y DO YOU WANT FORTRAN CODE (YIN) Y MAIN B2DR B2DI PB2DR PB2DI PRINT CHAR DIGITS DIGTSR ***OK*** **** STOP OK, CO TTY
Run-time monitoring code is inserted in the FORTRAN code generated by the ROOTS preprocessor by the insertion of a .MONITOR statement as described above. The FORTRAN code should be compiled in the normal way, but when the program is loaded, commands:
LO PROGRAM>B_ROOTSMON LI VFLIB LI VAPPLB
should be included. To continue the example above:
OK, FTN C-SOURCE -DYNM [ -DYNM is used because source contains recursive routines
GO
0000 ERRORS [<.MAIN.>FTN-REV15.2]
0000 ERRORS [<B2DR >FTN-REV15.2]
0000 ERRORS [<B2DI >FTN-REV15.2]
0000 ERRORS [<PB2DR >FTN-REV15.2]
0000 ERRORS [<PB2DI >FTN-REV15.2]
0000 ERRORS [<PRINT >FTN-REV15.2]
0000 ERRORS [<CHAR >FTN-REV15.2]
0000 ERRORS [<DIGITS>FTN-REV15.2]
0000 ERRORS [<DIGTSR>FTN-REV15.2]
OK, SEG
GO
# VLOAD #C-SOURCE
$ LO B C-SOURCE
$ LO PROGRAM>B_ROOTSMON
$ LI VFLIB
$ LI VAPPLB
$ LI
LOAD COMPLETE
$ SA
$ QU
When the program is run, a dialogue will be initiated by the run-time monitor as shown below:
OK, SEG #C-SOURCE
GO
BUFFER TYPE(1:HIST,2:CIRC)
1
PLEASE INPUT CHANNEL NO FOR OUTPUT
11
PLEASE INPUT PERFORMANCE FILENAME
SOURCE-P
PLEASE INPUT CONTROL PATHS FILENAME
SOURCE-C
PLEASE INPUT SNAP-SHOT FILENAME
SOURCE-S
PLEASE INPUT TRACE FILENAME
SOURCE-I
TRACE ACTIVE?(T OR F)
T [ TRACE is suppressed by replying F
PLEASE INPUT LEVEL OF DETAIL OF TRACE
30 [ sets level of detail for this run
PLEASE INPUT MAXIMUM REFINEMENT TRACED
20 [refinements deeper than this are not traced
PLEASE INPUT LENGTH OF STATEMENT
IN CHARACTERS REQUIRED IN TRACE
80 [the first 80 characters of each statement traced are recorded in the buffer
3 [remaining input typed is data for program
-123
5436
1
-123 -123 -123
5436 +5436 +5436
9999
[ output below is summary of resources used by monitor itself
PERFORMANCE MONITOR FOR MONITORING SUBROUTINE
TOTAL CPU-TIME= 980
TOTAL I/0-TIME= 2
FREQUENCY= 995
**** STOP
OK,
This section describes, by way of the above example the production of flowcharts from the flowchart code files produced by the ROOTS preprocessor and the run-time monitor.
The example below shows the commands necessary to display the run-time performance and snap-shot data on a flowchart of the program source. The detailed description of the parameters to the flowchart program is deferred to a later section.
The flowchart generation program is invoked by the command:
SEG PROGRAM>#ROOTSFLOW
The user is then asked to specify those parameters for this task which differ from the default parameters set up by the flowchart generation program, as shown below:
OK, SEG PROGRAM >#ROOTSFLOW
GO
DIMENSIONAL FLOWCHARTING PROGRAM, VERSION RECURS 7.0
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
Y
PARAM WANTED DEFAULT INPUT ! PARAM WANTED DEFAULT INPUT ACTDEL " 1 ! FRAME WIDTH 6000 14 CONDEL ? 2 ! FRAME HEIGHT 6000 15 REFBEG ! 3 ! CHAR WIDTH 6 16 ABSBEG 4 ! CHAR HEIGHT 4 17 PARBEG = 5 ! SPACING 2 18 REFEND # 6 ! DIAG 8 19 RPTEND * 7 ! DTB 3 20 PAREND # 8 ! DMLP 40 21 DRWDYN + 9 ! DEVICE PLOT 22 NOTDYN - 10 ! TRACE LEVEL 0 23 FOREST T 11 ! DYNAMIC INFO F 24 STMCUT 25 12 ! GRID WANTED F 25 FRMSIZ 100 13 ! DIVISIONS 10 26 INFILE INFOFC 27 DYNFIL DYNFO 28 OUTFIL FLOWIT 29 DEBUG DEBUG 30 SNPFIL SNAPS 31 PLTFIL BPLOTTER 32 SNPSHT F 33 ! NO OF DYNAMS 2 34
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE ? (I2)
12
WHAT DO YOU WANT TO USE INSTEAD ? -I4-
100
DO YOU WANT TO SEE THE PARAMETERS ? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER ? (Y OR N) -A1- l.
Y
WHICH DO YOU WANT TO CHANGE ? (I2)
27
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
F-SOURCE [ the flowchart code from ROOTS
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
28
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
SOURCE-P [ run-time performance file
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
31
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
SOURCE-S [ run-time snap-shots file
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
24 [ flag to display performance data
WHAT DO YOU WANT TO USE INSTEAD? -L1-
T
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
33 [ flag to display snap-shots
WHAT DO YOU WANT TO USE INSTEAD? -L1-
T
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
32
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
P-SOURCE [ file to contain plotter code
[ for Benson 1302 - default output device
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
Y
PARAM WANTED DEFAULT INPUT ! PARAM WANTED DEFAULT INPUT ACTDEL " 1 ! FRAME WIDTH 6000 14 CONDEL ? 2 ! FRAME HEIGHT 6000 15 REFBEG ! 3 ! CHAR WIDTH 6 16 ABSBEG 4 ! CHAR HEIGHT 4 17 PARBEG = 5 ! SPACING 2 18 REFEND # 6 ! DIAG 8 19 RPTEND * 7 ! DTB 3 20 PAREND # 8 ! DMLP 40 21 DRWDYN + 9 ! DEVICE PLOT 22 NOTDYN - 10 ! TRACE LEVEL 0 23 FOREST T 11 ! DYNAMIC INFO F 24 STMCUT 25 12 ! GRID WANTED F 25 FRMSIZ 100 13 ! DIVISIONS 10 26 INFILE F-SOURCE 27 DYNFIL SOURCE-P 28 OUTFIL FLOWIT 29 DEBUG DEBUG 30 SNPFIL SOURCE-S 31 PLTFIL P-SOURCE 32 SNPSHT T 33 ! NO OF DYNAMS 2 34
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1- N O.K. "ADVANCE FRAMES 0"- DO YOU WANT THE HISTOGRAMS ?(Y OR N -A1-) N "THE TOTAL CPU TIME USED BY THIS PROGRAM = 1872 THE TOTAL I/O TIME USED BY THIS PROGRAM = 106 IN HUNDREDTHS OF A SECOND THE NUMBER OF RECORDS READ WAS : 354 THE CHAR POSN ON THE RECORD WAS : 27 THE NUMBER OF CHARACTERS WAS : 42714"- **** STOP OK,
The output from the flowchart may be sent to the Benson plotter by the command
PLOT P-SOURCE
The next example describes the commands necessary to plot the run-time trace of the program as a flowchart on the Benson plotter.
OK, SEG PROGRAM >#ROOTSFLOW
GO
DIMENSIONAL FLOWCHARTING PROGRAM, VERSION RECURS 7.0
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
12
WHAT DO YOU WANT TO USE INSTEAD? -I4-
100
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
27
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
SOURCE-T [ trace file produced by monitor
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
32
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
P-SOURCE-TRACE [ plotter code output file
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
34 [ it is imperative this parameter be changed
[ the program will fail illegal dyn-char if this
[ is omitted
WHAT DO YOU WANT TO USE INSTEAD? -I4-
1
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
N
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
N
O.K.
"ADVANCE FRAMES 0"-
"ADVANCE FRAMES 1"-
DO YOU WANT THE HISTOGRAMS? (Y OR N) -A1-
N
"THE TOTAL CPU TIME USED BY THIS PROGRAM = 2292
THE TOTAL I/O TIME USED BY THIS PROGRAM = 15
IN HUNDREDTHS OF A SECOND
THE NUMBER OF RECORDS READ WAS : 465
THE CHAR POSN ON THE RECORD WAS : 13
THE NUMBER OF CHARACTERS WAS : 56146"-
**** STOP
OK,
This section gives a complete description of the program for drawing Dimensional Flowcharts. The program is used to draw a dimensional flowchart on the TEKTRONIX 4010 and 4014, the line-printer, the Benson 1302 plotter or the FR80 microfilm recorder. The input file contains flowcharting code as generated by the FORTRAN preprocesser FOREST.
The program may be loaded by:
SEG PROGRAM>#ROOTSFLOW
The program then asks the user if he wishes to see the parameter table. If the answer 'Y' is given to this question, the current parameter table will be displayed. Parameters may be changed as shown below. After each parameter change the user is given the opportunity to display the current parameter table.
Parameters may be changed as follows (the characters in brackets indicate the format of the response):
OK, SEG PROGRAM>#ROOTSFLOW
GO
DIMENSIONAL FLOWCHARTING PROGRAM, VERSION RECURS 7.0
DO YOU WANT TO SEE THE PARAMETERS? (Y OR N) -A1-
Y
PARAM WANTED DEFAULT INPUT ! PARAM WANTED DEFAULT INPUT ACTDEL " 1 ! FRAME WIDTH 6000 14 CONDEL ? 2 ! FRAME HEIGHT 6000 15 REFBEG ! 3 ! CHAR WIDTH 6 16 ABSBEG 4 ! CHAR HEIGHT 4 17 PARBEG = 5 ! SPACING 2 18 REFEND # 6 ! DIAG 8 19 RPTEND * 7 ! DTB 3 20 PAREND # 8 ! DMLP 40 21 DRWDYN + 9 ! DEVICE PLOT 22 NOTDYN - 10 ! TRACE LEVEL 0 23 FOREST T 11 ! DYNAMIC INFO F 24 STMCUT 25 12 ! GRID WANTED F 25 FRMSIZ 100 13 ! DIVISIONS 10 26 INFILE INFOFC 27 DYNFIL DYNFO 28 OUTFIL FLOWIT 29 DEBUG DEBUG 30 SNPFIL SNAPS 31 PLTFIL BPLOTTER 32 SNPSHT F 33 ! NO OF DYNAMS 2 34
DO YOU WISH TO CHANGE A PARAMETER? (Y OR N) -A1-
Y
WHICH DO YOU WANT TO CHANGE? (I2)
27
WHAT DO YOU WANT TO USE INSTEAD? -32A1-
TESTFC
Once all the parameters are correct, type 'N' to the question 'DO YOU WISH TO CHANGE ANY OF THESE?' The flowchart will then be drawn in vertical strips for the appropriate device. Each of these strips is made up of a number of frames.
The program automatically collects data about the frequency of use of various flowcharting constructs such as the number of characters per statement and the number of statements per refinement. These histograms give a clue to the complexity of the program and areas of poor structure. When the program has completed the flowchart, or an error has occurred, the question
'DO YOU WANT THE HISTOGRAMS?'
is asked. If the histograms are required they will be written to the output file.
| ( 1) | 'ACTEL' | Action statement delimiter | |
| ( 2) | 'CONDEL' | Conditional statement delimiter. | |
| ( 3) | 'REFBEG' | Beginning of refined sequence. | |
| ( 4) | 'ABSBEG' | Beginning of abstracted sequence. | |
| ( 5) | 'PARBEG' | Beginning of parallel sequence. | |
| ( 6) | 'REFEND' | Refined sequence terminator. | |
| ( 7) | 'RPTEND' | Repeated sequence terminator. | |
| ( 8) | 'PAREND' | Parallel sequence terminator. | |
| ( 9) | 'DRWDYN' | Dynamics information is required. | |
| (10) | 'NOTDYN' | Dynamics information is not required. | |
| (11) | 'FOREST' | * | The above parameters are FOREST by default. For DRIL input this is set to false and all parameters are automatically set to their DRIL equivalents. |
| (12) | 'STMCUT' | * | Number of characters appearing for each statement. This should be given some large value, say 100, if all the code is wanted. The shortened code lines produce a general outline of the structure of the flowchart. |
| (13) | 'FRMSIZ' | * | The coordinate system in which the grid will be drawn. This parameter has no effect on the size of the flowchart, but determines the scale of the grid i.e. the first frame will have top left-hand corner (0,0) and bottom right-hand corner (FRMSIZ,FRMSIZ). This means that large flowcharts need not have excessive scales |
| (14) | 'FRAME WIDTH' | Width of one output frame on selected device. | |
| (15) | 'FRAME HEIGHT' | Height of one frame. | |
| (16) | 'CHAR WIDTH' | Width of one output character. | |
| (17) | 'CHAR HEIGHT' | Height of half a character. | |
| (18) | 'SPACING' | Width of inter-character spacing. | |
| (19) | 'DIAG' | Length of diagonal refinement line. | |
| (20) | 'DTB' | Length of vertical line between consecutive statements. | |
| (21) | 'DMLP' | Gap between parallel sequences. | |
| (22) | 'DEVICE' | ** | Device on which flowchart is to be drawn.
On inputting this parameter number
the following list is given showing which
value to input:
WHAT DO YOU WANT TO USE INSTEAD ? (I1) DEVICE INPUT --------------- TEK 4010 1 TEK 4014 2 FR80 3 L.P. 4 BEN PLOTTER 5 |
| (23) | 'TRACE LEVEL' | * | The depth of trace desired for the program e.g.
0=None.
10=Basic outline i.e. coordinates of frame.
20=Entry to and exit from the recursive
subroutines which draw the sequences
30=Information about each sequence
i.e. refined or parallel, abstracted,
intersecting or windowed out,
repeated or earthed,
sequence number and sequence table.
40=Statement level i.e. action or conditional.
50=Statement details.
80=Lines - diagonal, vertical and horizontal.
90=Next non-blank character on input, statistics updating.
100=Every character from input file, coordinates for writing text.
120=The function MAX, each line of input.
The tracing information will be written into
the debug file which may then be passed
through this program to produce a 3-d trace.
|
| (24) | 'DYNAMIC INFO' | This must be set to true if run-time performance analysis is wanted. | |
| (25) | 'GRID WANTED' | * | It is possible to draw a grid around the flowchart by setting this value to true. |
| (26) | 'DIVISIONS' | * | Number of divisions in the grid for each frame. |
| (27) | 'INFILE' | ** | Input file containing flowcharting code. The filename may be up to 32 characters long, and may include tree names. |
| (28) | 'DYNFIL' | File for performance information as produced by the monitor The file will not be opened unless no.24 is set to true. | |
| (29) | 'OUTFIL' | ** | File in which flowchart for the line-printer and the histograms for all devices (if required) will appear. |
| (30) | 'DEBUG' | * | The debug file will contain the last piece of input and any error message produced. It will also hold the tracing output. |
| (31) | 'SNAPS' | * | File containing snap-shot values output by the monitor |
| (32) | 'PLTFIL' | * | File for plotter orders if output device is Benson plotter (5) |
| (33) | 'SNPSHT' | * | Set to true if snap-shots are to be displayed on the flowchart |
| (34) | 'NO OF DYNAMS' | Set to 1 if drawing flowchart of runtime execution trace generated by monitor. |
* - may be changed ** - most often changed
To draw a flowchart on the TEKTRONIX devices, first select the correct device number in the parameter table (No.22 - 1 for TEK 4010 and 2 for TEK 4014). 0ther parameters which may need changing are the grid decision, since this will be necessary to help with focussing, and the statement cut off length.
The frames will be drawn starting with the top left-hand corner and then moving down the flowchart to the bottom. If the flowchart is wider than the screen a number of these vertical strips will be drawn. The pause after the first frame is drawn will always be longer than any other since the program must process the whole code at this time.
After each frame there is a choice of three possible alternatives:
DO YOU WISH TO GO ON TO THE NEXT FRAME?(Y OR N -A1-)
N
YOU CAN EITHER BREAK(B),OR FOCUS ON A SEQUENCE(F)(-A1-)
F
PLEASE TYPE X-COORDINATE,MAX RIGHT= 126 (-I12-)
0
PLEASE TYPE Y-COORDINATE,MAX BOTTOM= 250 (-I12-)
85
When the flowchart has been drawn, or the user has broken in (by typing 'B'), the program asks 'DO YOU WANT THE HISTOGRAMS?'. If the response is 'Y' the histograms will be written to the output file.
To produce output for the FR80 choose device number 3 (parameter 22), decide on the statement cut off (which is usually enough to give the whole code, since the FR80 output is smaller). It is also possible to draw a grid around the flowchart by setting parameter NO. 25 to true.
During the program run the number of frames being drawn is written to the screen (i.e. 'ADVANCE FRAMES 0') to give an indication of how long the program is taking, and the size of the finished flowchart. These numbers start at zero, the largest number advanced showing how long the flowchart will be, and the number of times this figure returns to zero saying how many strips will have been drawn.
When the program has finished and asked whether the histograms are required, the FR80 output will be found in the file FR80JB. This must be sent across to the FR80 via the IBM 360/195.
E.G. HASP
GO
REV 15.02.00
INIT DONE
>SEND FR80JB
>QU
If the flowchart is wider than one strip, the FR80 hard copy, which appears in a continuous strip, should be cut along the cut lines and joined together.
The device number for the line-printer is 4. The program will advance frames similar to the FR80 and the flowchart, which will be written to the output file, must be spooled with the FORTRAN control option.
The device number for the Benson 1302 plotter is 5. The program will advance frames similar to the FR80. To plot the output on the Benson, issue the command:
PLOT <PLTFIL>
ERR = (I3) SEE PRIME USER NOTE 13- Error in opening file.
IERR = 0 O.K.
1 Illegal unit
2 Illegal file name
3 Illegal key
4 File does not exist
5 File protected
6 File in use
7 File exists
8 File directory full
9 Disc full
99 Unusual error
ERR-NO.(I3) IN CLOSING INPUT FILE, SEE PRIME USER NOTE 13
ERROR IN CLOSING I/O FILES
IERR = 0 O.K.
1 Illegal unit
10 Unit not open
99 Unusual error
ERR-IN RDL1N$, NO.=(I3) ACTREC=(I8)- Error in reading in a line of input.
ERR-GET NON BLANK CHARACTER (A1)- Null line in input.
ERR-E.O.F. REACHED IN READCH- End of file has been reached.
Could be due to mismatched !'s and #'s.
ERR-BAD STATMT DELIM (A1)- Illegal character at beginning of statement.
ERR-IN SKIP SEQUENCE (A1)(I4)- This character is neither
a refinement controller or statement delimiter.
ERR-BAD DYN CHAR=(A1)- Illegal character after statement
i.e. not DRWDYN or NOTDYN.
ERR-MAX CHARS PER STATMT (A1)- More then 999 characters in one statement.
ERR-BAD 1ST CHAR IN DYN DATA REC- Dynamics information does
not begin with a left bracket.
ERR-BAD SEQ TERM IN WINDOW(A1)(18)- Sequence terminator is
neither REFEND, PAREND or RPTEND.
ERR-MAX STMTS PER SEQ- More than 100 statements in one sequence.
ERR-MAX SEQS PER REF- More than 100 sequences in one refinement.
ERR-SEQUENCE TABLE OVERFLOW- More than 750 sequences.
ERR-MORE THAN 5 DIGITS IN NO.- Scale on grid has grown too
large. Redraw flowchart with smaller FRMSIZ or without grid.
To simulate recursion a stack is used in calling the subroutines which draw the sequences. These may not recurse to a depth of more than 200. If this happens the following messages will be given:
ERR-STACK OFLO IN CALLING DWSEQN ERR-STACK OFLO IN CALLING DSEQN ERR-STACK OFLO IN CALLING COMPND
The following error messages arise in the event of an internal error being detected by the program. Occurrence of such error messages should be reported to the authors of this program, after careful checking of the input data to the program.
ERR-MYSTERIOUS ERROR IN READCH ERR-CH OVER PAGE ARRAY BOUND(15I8) ERR-MYSTERIOUS ERROR IN DSTATM ERR-CHSIZE ERR-HISTGM LOOP GUARD ERR-FLNAME CONTAINS 34 CHARS NON-BLANK
A common error, which is not detected by the program, but which results in the bottom of the flowchart being lost, is caused by mismatched !'s and #'s. In this case the input data has indicated that the rest of the flowchart continues over the leftmost boundary. However, once the flowchart has gone beyond this limit the program will stop.
1. R W Witty, 'The design and construction of hierarchically structured software', 'Pragmatic Programming and Sensible Software', ONLINE Conference 1978.
2. N Wirth, 'Program Development by Step-Wise Refinement', CACM, Vol 7 No 5, Sept/Oct (1977).
